DragonDinghy

DragonDinghy is a multi-purpose expansion board for Klipper. See below for full specifications.DocumentationInternational ResellersBuy from JB3D.uk Buy from OneTwo3DBox ContentsDragonDinghy PCB10x PH Housing, 2 pin7x PH Housing, 3 pin5x PH Housing, 5 pin60x PH Crimp Contacts3x 1x4 Pin Header10x Jumper with HandleTechnical specifications: 9 Thermistor Inputs 5 Inputs best suited for 100k NTCs, like Generic 3950 or ATC Semitec 4 Inputs best suited for PT1000 4 Fan Outputs 2 GND-switched PWM fan ports with optional tachometer support, 1 A per port 2 4-pin Fan Ports, 2A maximum per port Each fan output supports 5V, 12V and 24V fans 4 RGB Outputs (compatible with WS2812B, SK6812 and Adafruit Neopixel) Integrated diagnostic SK6812 RGB LED up to 2A (shared with other 5V devices and across all 4 ports) 2 I²C ports Integrated 12V 2A and 5V 2A step-down converters Usage via CAN or USB (or...use it as an USB to CAN bridge?) Raspberry Pi compatible mounting pattern Extensive Quality-of-Life Features All ports are labeled on the board with the pinout and the respective pin for Klipper Klipper menuconfig settings are printed on the board Diagnostic LEDs for fan ports, DFU mode and power supply status Protection Features Reverse Polarity Protection on the main input Thermistor inputs withstand accidental short to 24V

€39.00*

5A Plus

PT1000 Cartridge, 3x15mm

1pcs PT1000 Temperatur Sensor3x15mmTemperature Range: -40°C~450°C1m Cable lengthWire Insulation: Mica High Temperature (up to 550°C)Copper Cartridge - can change color during operation due to oxidizationXH connector

€9.00*

Details

XH Coupler, 2 pin

JST XH coupler, allows you to join two XH connectors together. Manufacturer Number B2B-XH-TW (LF)(SN)

€0.30*

Omron

Omron D2F-L3

Omron D2F-L3 microswitch with simulated roller lever. Suitable for Filamentalist and applications where you "just need to bridge a bit more of a gap" (X endstop mounted at the Voron Carriage in conjunction with a G2E, for example)

€1.49*

Replimat Labs

GT2 Belt Tension Meter Hardware Kit by PF Makes

Hardware Kit for the GT2 Belt Tension Meter by PF MakesOriginal Project with assembly instructionsCan optionally be bought with a 5g tube of grease.BOM:1M3x6 BHCS1M3x25 SHCS13x8.8x0.6mm Washer22x10mm Self-Tapping Screws1Steel Spring 6mm OD x 0.6mm wire diameter, 50mm length10.81mm x 100mm (0.032” x 4”) Tempered steel music wire AKA "piano wire" (sourced from USA or local alternatives, verified to be equivalent)

From €8.50*

Details

HELUKABEL

Heluflon FEP-6Y

Heluflon FEP-6Y wire, made by Heluflon. Suitable for use within cable chains or in umbilical applications. Sold by the meter, you will receive the ordered quantity uncut, for example: Order 5 pcs, you receive 5m uncut.Most important specifications:Temperature Range-100C to +180CNominal Voltage600VMinimum bending radiusflexing 10x outer ⌀

From €0.90*

Details

40x40x28

Nevermore Mini

12V

Wakefield Thermal

Wakefield DS0402812V2B-BT0 30000 RPM "The Monster"

40x40x28mm fan for use in the Nevermore Mini. Extremely powerful fan which can be controlled via the PWM pin down to sub-10%. The performance of this fan is extremely high, so is it's noise, hence "The Monster". Mount the fan prior turning it on, it will probably jump at you. This fan is loud, fast and draws 3A at full speed. Using a standard fan output on your controller will probably kill the output, use an appropriate output like a spare hotend output.The datasheet can be found here.Pin Mapping:Red+Black-YellowTachometerBluePWM controlPWM control follows the standard Intel Spec (5V pullup, 25kHz signal). If no signal is given via the PWM input, the fan will run at full speed. Relevant config options for Klipper:tachometer_pin: # Set to the pin you like to use. Make sure it has either a hardware or software pullup tachometer_ppr: 2 tachometer_poll_interval: 0.001 cycle_time: 0.00004 hardware_pwm: true # Hardware PWM is preferred if your board is capable of it Technical data:Operational Voltage (nominal)12VRotational Speed30000 RPMAir Flow1 m³/min (35cfm, 60m³/h)Static Pressure5.88 inAQNoise Level66dBCurrent3000mA

€25.00*

Replimat Labs

Extruder Thumbscrew, M3x20

Black extruder thumbscrew, M3x20, fitting for most extrudersDIN653, Carbon Steel

€0.90*

Replimat Labs

Bambulabs A1 mini Silicone Nozzle Wiper

1pcs Bambulabs A1 mini Silicone Nozzle WiperExample project for your Voron 2.4 (probably also works on a Trident) can be found here

€0.50*

Replimat Labs

Bambulabs A1 Silicone Nozzle Wiper

1pcs Bambulabs A1 Silicone Nozzle WiperExample project for your Voron 2.4 (probably also works on a Trident) can be found here

€0.50*

5A Plus

24V 70W Heater Cartridge 6x20mm

24V 70W Heater Cartridge 6x20mmPower tolerance: -5/+25%

€6.50*

Linneo

Nevermore Boost (Activated Carbon / Scorch) S 750ml

Pre-mixed scorch (50% Scorch 50% Activated Carbon) 750ml

Content: 750 Milliliter (€18.00* / 1000 Milliliter)

€13.50*

Details

Nevermore StealthMax S Acrylic Panel ⌀200mm, 3mm thick

⌀ 200mm, 3mm thickness. Comes with protective film.

€6.39*

Fushi F695-2RS ABEC-9 Bearing

ABEC-9 precisionPhoto shows the ABEC-7 variant, the ABEC-9 variant is blue

€1.19*

Omron

Omron D2F-01

Omron D2F-01 Microswitch without lever. Suitable for Z-Endstop and the Klicky Probe. Photo shows the regular D2F variant, you will receive the D2F-01 variant

€1.29*

DragonBurner LED Diffusor printed part - Micron

DragonBurner Diffusor Variant: Micron

The DragonBurner Diffusor, printed in transparent PETG. We include 2 pieces because print defects are pretty hard to spot. Variants: Micron, Printer for Ants, Voron, Pitchfork

€0.50*

A4T Toolhead LED Diffusor printed part

The A4T Diffusor, printed in transparent PETG. We include 2 pieces because print defects are pretty hard to spot.

€0.50*

30x30x10mm

Dragonburner, V0

12V, Tachometer

Sunon

Sunon MF30101V1-1000U-G99

Sunon MF30101V1-1000U-G99 with tachometer output. Comes with an 1N4148 diode and instructions for the tachometer open collector output. Every fan is padded with some bubble wrap for additional protection during shipping. The small blobs on the fan are for imbalance compensation and are not a manufacturing defect! Technical data: Operational Voltage (nominal) 12V Rotational Speed 11500 RPM Air Flow 0.16 m³/min (5.5cfm, 9.6m³/h) Static Pressure 0.25 in H2O Noise Level 23.0dB Current 0.55mA

€13.99*

Igus CF9.05.04

Igus CF9.05.04 cable, suitable for use in 3D printer CAN bus applications. Price per meter. Full length without cut, for example: 2 pcs = 2m. Important: Measure the required distance yourself, however, 3m should be plenty for both a Trident and v2.4 setup, regardless of the build size and electronics bay routing. The usual rule applies: Measure twice, cut once.

€5.80*

30x30x10mm

Dragonburner

24V

Gdstime

Gdstime GDA3010, Dual Ball Bearing, 24V

Gdstime 3010 Fan, suitable for DragonBurner. Model Number GDA3010. Dual Ball Bearing, 24V, 60mA, 12000 RPM, 4.7 cfm, 27dB(a), 0.47 InH2O

€8.90*

XoL Toolhead PCB

This is a PCB made for Armchair Engineering's Xol Toolhead, featuring: One hotend cooling fan JST-XH connectors Two part cooling fan JST-XH connectors One heater Micro-Fit connector One thermistor Micro-Fit connector One Neopixel JST-XH connector Two auxiliary JST-XH connectors One extruder motor connector Selectable fan voltage (5V, Alt, 24V) Integrated mount for carriage screw This PCB is not pre-soldered, you need to solder it yourself.

€9.90*

Details

Nevermore Mini & Stealthmax PCB

This small open-source controller is used to control your Nevermore StealthMax or Mini using Klipper. You can use CAN or USB, depending on your requirements. It also has connectors, so you can hook up sensors to measure VOCs. Note that this is designed only for 4 wire fans, where the fan speed is controlled via a separate wire. This board cannot be used with your 2 wire fans or 3 wire fans with tachometer. A suitable fan would be the GdsTime GDP4028. Features: 1x 4 pin fan connector 2x HW I2C, 1x Optional Sensor Module Mount 1x Neopixel 1x CAN Installation instructions can be found on the GitHub Repository. Since we test all boards, you can skip steps 1-6. Designed by Isik's Tech

€24.90*

Details

BME280 & SGP40 Sensor PCB for Nevermore Air Filters

A compact PCB with SGP40 and BME280 sensors wired in I2C mode and powered with 3.3V. Comes with straight and right-angle pin headers, so you're flexible with the installation. The I2C address of the BME280 is 119, make sure you configure it as i2c_address: 119 in your software. To make use of the SGP40 sensor in Klipper, you need an additional module. Installation instructions can be found on the Nevermore Max Repository. Documentation can be found on GitHub. Designed by Isik's Tech

€24.99*

YOUMETONG

MGW7C 40mm medium preload rail+carriage

YOUMETONG MGW7C 40mm rail with medium preload carriage, 5mm edge-to-hole distance Suitable for MetalBoop

€17.90*
